Keystone S/K-50 WIL Standard Duty Cavity Wall Lintel 750mm

SKU

KS5WIL075

£43.60 £36.33

Product Information

Keystone S/K-50 WIL cavity wall lintel, 750mm (29½") length for standard-duty load-bearing openings.
Designed for cavity widths between 50-65mm and inner leaf blockwork 125-150mm wide.
Ideal for supporting window and door openings in cavity walls with wide inner leaves.
Ensure inner leaf blockwork does not overhang lintel flange by more than 25mm for secure installation.
Lintels should be propped during construction to speed up the build process and ensure safety.

Details

The Keystone S/K-50 WIL 750mm is a standard duty cavity wall lintel engineered for professional builders, contractors, and site managers. It offers dependable support for openings in cavity walls with a 50-65mm cavity and a wide inner leaf blockwork of 125-150mm. This lintel is a practical choice when working on structural openings requiring robust, reliable materials. Please note that lintels must be propped during installation to maintain structural integrity and speed up construction.

Application

This lintel is primarily used to span openings such as windows and doors in cavity walls where the inner leaf blockwork is wider than standard. It supports the load above the opening, ensuring stability and preventing structural movement. Ideal for use in both residential and commercial masonry projects where standard duty loading is applicable.

Dimension

Length: 750mm (29½")
Height: 91mm
Width (flange): 268mm
Cavity range: 50-65mm

Material

Steel lintel with protective coating suitable for cavity wall installation

Type

Cavity wall lintel – wide inner leaf, standard duty

For optimal performance, ensure the inner leaf blockwork does not overhang the lintel flange by more than 25mm. If you require further technical support, please contact the Keystone Technical Office directly.

More Information

More Information
Type	Wide Inner Leaf Lintels
Loading	Standard Duty
Cavity Size	50-65mm
Length	750mm
Weight	5.360000
Manufacturer	Keystone
Sap Id	KS5WIL075
