Keystone BOX/K-150 Solid Wall Box Lintel 1650mm INS

SKU

KBX15165INS

£64.78 £53.98

Product Information

Keystone BOX/K-150 Solid Wall Box Lintel, 1650mm (5ft 5in) length
Designed for 150mm (6in) wide solid walls, ideal for internal openings
Includes built-in insulation for improved thermal efficiency (INS version)
Perforated design provides excellent plaster key for finishing
Lintel requires minimum 150mm bearing on each side; bedded on mortar

Details

The Keystone BOX/K-150 Solid Wall Box Lintel 1650mm INS is a specialist structural lintel designed for builders and site managers working on solid wall constructions. This insulated version enhances thermal performance while reliably supporting standard loads over internal openings in 150mm thick walls. Please note, lintels must be installed with the correct bearing and bedding to ensure performance.

Application

This box lintel is commonly used to span internal doorways and openings within solid masonry walls, providing dependable structural support during and after construction. The integrated insulation improves energy efficiency on site, helping meet thermal regulations without compromising load capacity. It is especially suited for new builds and refurbishment projects where thermal bridging reduction is a priority. Proper propping during installation is recommended to maintain construction progress and safety.

Dimension

Length: 1650mm (5ft 5in)
Height: 150mm (6in)
Width: 145mm (5.7in)
Designed for wall thickness between 100-215mm

Material

Galvanised steel with integrated insulation
Perforated surface for plaster adhesion

Type

Box lintel for solid walls
Standard duty load bearing lintel

All lintels require a minimum bearing of 150mm on each side, bedded on mortar for secure fixing. Keystone BOX lintels are manufactured in 150mm increments to suit project requirements. For further technical advice or installation guidance, please contact our sales team.

More Information

More Information
Type	Box Lintels
Loading	Standard Duty
Length	1650mm
Weight	13.260000
Manufacturer	Keystone
Sap Id	KBX15165INS
