Catnic CXL290 Extreme Load Cavity Wall Lintel - 2250mm

SKU

cxl290225

£661.00 £550.83

Product Information

Catnic CXL290 extreme load cavity wall lintel, length 2250mm (7ft 4½in)
Designed for 90-105mm cavity walls with 110-115mm inner leafs, perfect for robust structural support
Manufactured from Grade S275 structural steel with post-manufacture galvanised finish for corrosion resistance
Supports heavy loads with required lateral restraint and minimum 200mm end bearing
Separate flexible DPC must be installed; lintel supplied without DPC

Details

The Catnic CXL290 Extreme Load Cavity Wall Lintel, measuring 2250mm in length, is engineered for demanding construction projects requiring strong, reliable lintel support. It is specifically designed for cavity walls with a 90-105mm cavity and an inner leaf thickness of 110-115mm. This lintel offers peace of mind for builders and contractors handling heavy structural loads.

Application

This lintel is ideal for use in cavity wall construction where extreme load-bearing capacity is required. It suits both residential and commercial developments where robust support across openings such as doors and windows is critical. The lintel must be laterally restrained on site and installed with a minimum 200mm bearing at each end to meet load specifications. A separate flexible damp proof course (DPC) must be incorporated during installation to prevent moisture penetration.

Dimension

Length: 2250mm (7ft 4½in)
Suitable for cavity widths: 90-105mm
Inner leaf thickness: 110-115mm

Material

Universal beam section and 6mm structural grade steel plate (Grade S275 to BS EN10025: 2004)
Post-manufacture galvanised finish to BS EN ISO 1461: 1999 for enhanced corrosion resistance

Type

Extreme loading cavity wall lintel

Note: This lintel is supplied without a damp proof course; a separate flexible DPC must be installed on site. Images are for illustration purposes only.

More Information

More Information
MPN	CXL290/2250
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	90-105mm
Length	2250mm
Weight	97.875000
Manufacturer	Catnic
Sap Id	cxl290225
