Catnic CXL265 Extreme Load Cavity Wall Lintel - 3950mm

SKU

cxl265395

£991.98 £826.65

Product Information

Catnic CXL265 extreme load cavity wall lintel, length 3950mm (13ft)
Designed for 70-85mm cavity and 110-115mm inner leaf thickness
Constructed from Grade S275 structural steel with a post-galvanised finish for corrosion resistance
Ideal for projects requiring heavy load support and reliable structural performance
Separate flexible DPC must be installed during construction

Details

The Catnic CXL265 Extreme Load Cavity Wall Lintel at 3950mm is engineered specifically for demanding structural applications. Perfect for builders and contractors working on cavity walls with 70-85mm cavities and 110-115mm inner leaf thickness, this lintel combines robust design with corrosion-resistant galvanised steel to ensure lasting reliability on site. Please note, a separate flexible DPC must be fitted during installation to maintain building integrity.

Application

This lintel is tailored for heavy-duty cavity wall construction where extreme load-bearing capacity is essential. It supports large openings such as windows and doors in both residential and commercial projects. Its structural steel and universal beam design provide the strength needed for inner to outer leaf load ratios between 5:1 and 19:1, assuming proper lateral restraint and minimum 200mm end bearing supports.

Dimension

Overall length: 3950mm (13ft)
Suitable for cavity widths: 70-85mm
Inner leaf thickness: 110-115mm
Available in 50mm increments up to 6600mm for other length requirements

Material

Grade S275 structural steel plate (6mm thickness)
Universal beam section
Post manufacture galvanised finish to BS EN ISO 1461:1999 for enhanced corrosion protection

Type

Extreme load cavity wall lintel

As an optional extra, the CXL lintel can be supplied with expanded metal mesh secured to the base plate to improve mortar keying. Images are for illustration only.

More Information

More Information
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	70-85mm
Length	3950mm
Weight	167.085000
Manufacturer	Catnic
Sap Id	cxl265395
