Catnic CXL265 Extreme Load Cavity Wall Lintel - 2850mm

SKU

cxl265285

£724.91 £604.09

Product Information

Catnic CXL265 extreme load cavity wall lintel, 2850mm (9ft 4in) length for robust structural support.
Suitable for 70-85mm cavity walls with 110-115mm inner leaf thickness, ideal for demanding building projects.
Manufactured from Grade S275 structural steel with a durable post-galvanised finish for corrosion resistance.
Lintel must be laterally restrained with 200mm end bearing supports; separate flexible DPC required on site.
Optional expanded metal mesh available for enhanced base plate reinforcement.

Details

The Catnic CXL265 Extreme Load Cavity Wall Lintel is engineered for builders and contractors handling heavy structural demands. At 2850mm long, it provides dependable support in cavity wall constructions where strength and durability are essential. Please note that a separate flexible DPC must be installed during building to ensure moisture protection.

Application

This lintel is designed for use in cavity walls with a 70-85mm cavity and an inner leaf thickness of 110-115mm. It is ideal for projects requiring extreme load-bearing capacity, such as multi-storey residential or commercial buildings. Its robust construction ensures stability where heavy masonry or structural elements rest above openings like doors and windows.

Dimension

Length: 2850mm (9ft 4in)
Cavity width compatibility: 70-85mm
Inner leaf thickness: 110-115mm

Material

Grade S275 structural steel to BS EN 10025:2004
Post-galvanised finish for enhanced corrosion resistance

Type

Extreme loading cavity wall lintel
Manufactured from universal beam section with 6mm steel plate

Lintels are supplied in 50mm length increments up to 6600mm. To meet the specified load ratings, lintels must be laterally restrained with a minimum of 200mm bearing at each end and support inner to outer leaf load ratios between 5:1 and 19:1. An optional expanded metal mesh can be fixed to the base plate for additional reinforcement if required.

More Information

More Information
MPN	CXL265/2850
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	70-85mm
Length	2850mm
Weight	120.555000
Manufacturer	Catnic
Sap Id	cxl265285
