Keystone XCFS/K-70 Extra Heavy Duty Cavity Wall Lintel 1950mm

SKU

KXCFS7195

£330.38 £275.32

Product Information

Keystone XCFS/K-70 lintel, 1950mm (6ft 5in) length for wide cavity wall openings.
Extra heavy duty design supports cavity widths from 70 to 85mm, ideal for robust structures.
Constructed to reliably bear heavy loads over door and window openings.
Recommended to prop lintels during installation for safe, efficient construction progress.
Ensure all perpendicular and horizontal joints are fully filled with mortar for maximum strength.

Details

The Keystone XCFS/K-70 lintel is an extra heavy duty cavity wall lintel, measuring 1950mm in length. It is specifically designed for builders, contractors, and site managers working on demanding projects requiring strong structural support over cavity wall openings between 70 and 85mm wide. Please note, proper mortar application and propping during installation are essential for optimal performance.

Application

This lintel is intended to support heavy loads above doorways, windows, or other openings in cavity walls with widths from 70 to 85mm. It is suitable for use in both residential and commercial building projects where structural integrity and durability are critical. To ensure even load distribution, a mortar bed should be applied on top of the blockwork before laying floor units. Propping the lintel during construction is recommended to maintain safety and speed up the build process.

Dimension

Length: 1950mm (6ft 5in)
Height: 235mm
Width: 263mm
Weight: 49.06kg

Material

Steel (galvanised for corrosion resistance)

Type

Extra heavy duty cavity wall lintel

Always ensure all perpendicular and horizontal joints are completely filled with mortar during installation. For further advice or technical support, please contact our sales team.

More Information

More Information
Type	Cavity Wall Lintels
Loading	Extra Heavy Duty
Cavity Size	70-85mm
Length	1950mm
Weight	49.060000
Manufacturer	Keystone
Sap Id	KXCFS7195
