Keystone XCFS/K-50 WIL Extra Heavy Duty Cavity Wall Lintel 1050mm

SKU

KXCFS5WIL105

£227.72 £189.77

Product Information

Keystone XCFS/K-50 WIL cavity wall lintel, 1050mm (41.3in) length for strong structural support.
Designed for extra heavy duty loads, ideal for wide inner leaf blockwork 125-150mm thick.
Suitable for cavity widths between 50-65mm, ensuring a precise fit on site.
Recommended propping during installation speeds up construction and ensures stability.
Inner leaf block must not overhang lintel flange by more than 25mm; mortar bed required for even load distribution.

Details

The Keystone XCFS/K-50 WIL 1050mm lintel is engineered for tradespeople and site managers working on cavity wall projects requiring extra heavy duty load-bearing capacity. Specifically designed to support wide inner leaf blockwork, this lintel provides dependable structural integrity for serious builds. Please note, inner leaf blocks must be correctly positioned and mortar bedding applied for optimal performance.

Application

This lintel is suited to cavity walls with a 50-65mm cavity and inner leaf blockwork thickness of 125-150mm. It’s ideal for supporting openings such as doors and windows where heavy structural loads are expected. The lintel flange should not be overhung by more than 25mm by blockwork to maintain stability. For best results, propping is advised during installation to accelerate build times and secure the lintel in place. Mortar should be bedded on top of the blockwork before laying floor units to ensure even load transfer.

Dimension

Length: 1050mm (41.3in)
Height: 235mm (9.25in)
Width: 268mm (10.55in)
Suitable cavity range: 50-65mm

Material

Manufactured from high-grade steel for maximum strength and durability
Protective coating to resist corrosion and extend service life on site

Type

Cavity wall lintel – wide inner leaf, extra heavy duty load class

All product descriptions are intended as a guide. For technical advice or specific project requirements, please contact our sales office directly.

More Information

More Information
Type	Wide Inner Leaf Lintels
Loading	Extra Heavy Duty
Cavity Size	50-65mm
Length	1050mm
Weight	27.040000
Manufacturer	Keystone
Sap Id	KXCFS5WIL105
