Keystone T/K-90 Standard Load Cavity Wall Timber Frame Lintel 4500mm

SKU

KT945

£248.74 £207.28

Product Information

Keystone T/K-90 lintel, length 4500mm (14ft 9in), designed for 90-105mm cavity walls.
Standard load capacity suitable for supporting outer brickwork in timber frame construction.
Ensures stability and prevents twisting when used with lateral restraint clips and timber battens.
Recommended to prop lintels during installation to maintain structural integrity and speed build.
All technical guidance available from Keystone Technical Office for confident specification.

Details

The Keystone T/K-90 Standard Load Cavity Wall Timber Frame Lintel is engineered specifically for timber frame projects requiring reliable support over openings. At 4500mm long, it is ideal for cavity walls with widths of 90-105mm, providing consistent load-bearing performance for outer brickwork. This lintel is a practical choice for builders and contractors focused on structural stability and efficient installation.

Application

This lintel is commonly used in timber frame cavity wall builds to support the outer leaf of brickwork above windows, doors, and other openings. Its design suits standard load requirements in residential and commercial timber frame construction. To ensure proper performance, the lintel should always be installed with lateral restraint clips and a tightly fitted timber batten to prevent twisting. Props are recommended during installation to maintain alignment and speed up the building process.

Dimension

Length: 4500mm (14ft 9in)
Height: 260mm (10¼in)
Width: 183mm (7¼in)
Cavity range: 90-105mm (3½-4in)
Weight: 45.22kg

Material

Engineered timber suitable for structural load-bearing in cavity walls

Type

Timber frame cavity wall lintel
Standard duty load-bearing lintel

Please note: This lintel must be used with lateral restraint clips and timber battens to ensure proper function. It is recommended to prop lintels during construction for safety and ease of installation. For any technical questions, please contact the Keystone Technical Office.

More Information

More Information
Type	Timber Frame Lintels
Loading	Standard Duty
Cavity Size	90-105mm
Length	4500mm
Weight	45.220000
Manufacturer	Keystone
Sap Id	KT945
