Siniat GTEC U Track Deep Flange UDT148/B 0.7mm x 148mm x 3000mm Pack of 10

SKU

gtecUDT148/B30

£22.70 £18.92

Product Information

Siniat GTEC U Track Deep Flange UDT148/B, dimensions 0.7mm x 148mm (5.83") x 3000mm (118.11")
Designed for drywall partitions exceeding 4.2m in height or deflection head applications
Lightweight steel section manufactured to BS EN 14195 with A1 fire reaction rating
Ideal for use as head or base track in single or twin framing systems on site
Easy to cut and install, reducing labour and material compared to timber alternatives

Details

The Siniat GTEC U Track Deep Flange UDT148/B is a specialist steel framing component engineered for drywall partitions taller than 4.2 metres or where a deflection head is necessary. Trusted by contractors and site managers, it offers a reliable, lightweight alternative to timber with assured fire resistance and compliance to BS EN 14195. Please note, the product is supplied as individual lengths for on-site cutting and assembly.

Application

This deep flange U track is primarily used as a head or base channel in drywall partition systems with single or twin stud framing. Its design accommodates partition heights exceeding 4.2 metres and provides the structural flexibility required in soffit areas where deflection heads are installed. Installation is straightforward using compatible GTEC screws and studs, making it a practical choice for commercial and residential projects demanding precision and durability.

Dimension

0.7mm (0.028") thickness x 148mm (5.83") width x 3000mm (118.11") length

Material

Galvanised steel manufactured to BS EN 14195 standards

Type

Metal framing track for drywall and plasterboard partition systems

More Information

More Information
MPN	4041923
Manufacturer	Siniat
Drylining - Type	GTEC Track
Drylining - Width	148mm
Drylining - Length	3000mm
Sap Id	gtecUDT148/B30
Availability	Generally available in 2 working days.
