Expamet SPHS12547 Sph STD Joist Hanger 125x47mm (Box of 40)

SKU

exp_SPHS12547/40

£84.00 £70.00

Product Information

Expamet SPHS12547 joist hanger, 125mm (4.92") x 47mm (1.85") dimensions for precise joist support
Box of 40 hangers ideal for builders, carpenters, and contractors working on multiple or large-scale projects
Single-piece, non-welded design with non-coaxial fixing holes for ease of installation and enhanced strength
Galvanized 600g/m² coating provides superior corrosion resistance for long-term durability
Installation requires joists cut square with max 6mm gap; joists to be nailed through side gusset with 3.75x30mm nails

Details

The Expamet SPHS12547 joist hanger is a reliable timber connector designed for trade professionals requiring consistent, secure joist support. Supplied as a box of 40, this hanger suits extensive projects where structural integrity and ease of installation are paramount. Please note installation guidelines must be followed to ensure optimal performance.

Application

Specifically engineered for supporting timber joists in studwork, flooring frameworks, and plasterboard ceilings, the SPHS12547 joist hanger provides stable load transfer between joists and supporting walls or beams. It is widely used in both new builds and refurbishment projects where reliable fixing and alignment of joists are critical.

Dimension

125mm (4.92") x 47mm (1.85")

Material

Galvanized steel with 600g/m² coating for corrosion protection

Type

Single-piece joist hanger (timber connector)

Installation Requirements: The back of the hanger must fit tightly against the wall, with joists cut square and a maximum 6mm gap from the rear of the hanger. A minimum of 675mm of set masonry should be present over the support flange before applying loads. Joists are to be fixed through the side gusset using 3.75x30mm square twisted nails. Additionally, the underside of joists should be notched to provide a level surface for plasterboarding.

More Information

More Information
Weight	15.060000
Availability	3 to 4 working days
Manufacturer	Expamet
MPN	SPHS12547
Material Gauge	2.0mm
Notified Body	Lucideon Ltd (NB 1289)
Length/Projection	75mm Shoe, 75mm Flange
Length/Height	125mm
Expamet - Product Range	Builders Metalwork
Plaster/Render/Joist Depth	47mm Joist Width
Expamet - Product Type	Masonry/Single Piece Hanger
Material	Galvanized Mild Steel DX51D+Z600 to EN10346:2015
European Standard	BS EN845-1:2013+A1:2016
Expamet - Product Sub Range	Joist Hangers
Test Standard	BS EN 846-8:2000
Coating/Finish/Colour	600g/m² Zinc Coating
Fire Rating	Euroclass A1
Declared Loadbearing Capacity	5kN SWL (SLS)
Sap Id	exp_SPHS12547/40
