Expamet SPHS10050 Sph STD Joist Hanger 100x50mm (Box of 40)

SKU

exp_SPHS10050/40

£77.40 £64.50

Product Information

Expamet SPHS10050 joist hanger, 100mm (3.94") x 50mm (1.97") dimensions for precise timber support
Box of 40 hangers, ideal for large-scale construction and repeat use
Galvanized coating (600g/m²) offers excellent corrosion resistance for durability
Single-piece, non-welded design with non-coaxial fixing holes for secure installation
Installation requires joists cut square with max 6mm gap and masonry set before load application

Details

The Expamet SPHS10050 joist hanger is a specialist timber connector designed for builders, carpenters, and contractors needing reliable, high-performance support for joists. Supplied in a box of 40, it suits larger projects requiring consistent quality and efficient installation. Please note, the joist hangers must be installed following specific guidelines to ensure structural integrity.

Application

These joist hangers are engineered to provide secure support for timber joists in studwork, flooring frameworks, and ceiling constructions. Their robust galvanized finish makes them suitable for internal and protected environments, ensuring long-term stability in residential and commercial builds. Ideal for contractors and developers requiring dependable fixings that simplify joist alignment and load transfer.

Dimension

100mm (3.94") x 50mm (1.97")

Material

Galvanized steel with 600g/m² coating for corrosion resistance

Type

Single-piece joist hanger (timber connector)

Installation notes: The back of the hanger must be flush against the supporting wall. Joists should be cut square with a maximum 6mm gap from the hanger rear. Ensure at least 675mm of set masonry is in place before applying load. Fix joists through side gussets with 3.75x30mm square twisted nails. Notching the underside of joists is recommended to provide a level surface for plasterboard fixing.

More Information

More Information
Weight	13.740000
Availability	3 to 4 working days
Manufacturer	Expamet
MPN	SPHS10050
Material Gauge	2.0mm
Notified Body	Lucideon Ltd (NB 1289)
Length/Projection	75mm Shoe, 75mm Flange
Length/Height	100mm
Expamet - Product Range	Builders Metalwork
Plaster/Render/Joist Depth	50mm Joist Width
Expamet - Product Type	Masonry/Single Piece Hanger
Material	Galvanized Mild Steel DX51D+Z600 to EN10346:2015
European Standard	BS EN845-1:2013+A1:2016
Expamet - Product Sub Range	Joist Hangers
Test Standard	BS EN 846-8:2000
Coating/Finish/Colour	600g/m² Zinc Coating
Fire Rating	Euroclass A1
Declared Loadbearing Capacity	5kN SWL (SLS)
Sap Id	exp_SPHS10050/40
