Catnic CXL350 Extreme Load Cavity Wall Lintel - 2850mm

SKU

cxl350285

£1,006.54 £838.78

Product Information

Catnic CXL350 Extreme Load cavity wall lintel, length 2850mm (9ft 4in)
Designed for 150-165mm cavity walls with 110-115mm inner leaf thickness
Manufactured from Grade S275 structural steel with a post-galvanised finish for corrosion resistance
Supports heavy structural loads when installed with 200mm end bearing and lateral restraint
A separate flexible DPC must be installed during construction for moisture protection

Details

The Catnic CXL350 Extreme Load cavity wall lintel is engineered specifically for builders and contractors tackling demanding structural openings. Its robust steel construction and precise design make it an excellent choice for cavity walls between 150 and 165mm, offering reliable support where heavy loads are involved. Please note that this lintel requires a separate flexible damp proof course (DPC) to be installed during construction.

Application

This lintel is ideal for large openings in cavity brick or block walls where extreme loading conditions apply. Typical uses include commercial and residential developments requiring strong lintel support for heavy masonry or structural elements. It must be installed with a minimum 200mm end bearing on each side and lateral restraint to achieve the specified load capacity. Inner to outer leaf load ratios should be maintained between 5:1 and 19:1 for optimal performance.

Dimension

Length: 2850mm (9ft 4in)
Designed for cavity widths of 150-165mm and inner leaf thickness of 110-115mm
Available in 50mm increments up to 6600mm for tailored applications

Material

Grade S275 structural steel plate and universal beam section
Post-galvanised finish for enhanced corrosion resistance

Type

Extreme load cavity wall lintel

Optional extras include lintels supplied with expanded metal mesh fixed to the base plate to aid plaster keying or render adhesion. Images are for illustration purposes only.

More Information

More Information
MPN	CXL350/2850
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	150-165mm
Length	2850mm
Weight	131.670000
Manufacturer	Catnic
Sap Id	cxl350285
