Catnic CXL350 Extreme Load Cavity Wall Lintel - 2600mm

SKU

cxl35026

£918.24 £765.20

Product Information

Catnic CXL350 Extreme Load cavity wall lintel, 2600mm (8ft 6in) length.
Designed for 150-165mm cavity walls with 110-115mm inner leaf thickness.
Manufactured from Grade S275 structural steel, post galvanised for superior corrosion protection.
Ideal for heavy load-bearing applications requiring reliable structural support.
Must be installed with a separate flexible DPC; lintel supplied without DPC.

Details

The Catnic CXL350 Extreme Load cavity wall lintel is engineered for builders and contractors tackling demanding structural projects. Its robust design and galvanised finish ensure lasting strength and corrosion resistance, making it an excellent choice for load-bearing openings in 150-165mm cavity walls with 110-115mm inner leaves. Please note, a separate flexible DPC must be installed during construction as this is not included.

Application

This lintel is suited to heavy-duty masonry openings where extreme loading conditions apply, such as large window or door spans in cavity walls. It provides dependable support across cavity widths of 150-165mm, commonly found on modern and traditional builds. The product is ideal for site managers and structural contractors who require consistent quality and compliance with building regulations.

Dimension

Length: 2600mm (8ft 6in)
Suitable for cavity widths: 150-165mm
Inner leaf thickness: 110-115mm
Available in standard increments of 50mm up to 6600mm on request

Material

Grade S275 structural steel to BS EN 10025:2004
Post-manufacture galvanised finish to BS EN ISO 1461:1999 for corrosion resistance

Type

Extreme load cavity wall lintel
Universal beam section with 6mm structural steel plate

For optimal performance, the lintel must be laterally restrained with 200mm bearing support at each end and installed with correct inner to outer leaf load ratios between 5:1 and 19:1. Optional expanded metal mesh attachment is available to enhance base plate anchorage if required.

More Information

More Information
MPN	CXL350/2600
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	150-165mm
Length	2600mm
Weight	120.120000
Manufacturer	Catnic
Sap Id	cxl35026
