Catnic CXL290 Extreme Load Cavity Wall Lintel - 5500mm

SKU

cxl29055

£1,615.75 £1,346.46

Product Information

Catnic CXL290 Extreme Load Cavity Wall Lintel, 5500mm (18ft 1in) length
Designed for 90-105mm cavity walls with 110-115mm inner leaf thickness
Manufactured from S275 structural steel with post-manufacture galvanised finish for durability
Supports heavy loads; requires lateral restraint and 200mm end bearing for optimal performance
Separate flexible DPC must be installed during construction

Details

The Catnic CXL290 is a high-capacity cavity wall lintel engineered for projects requiring extreme load support. Ideal for builders, contractors, and site managers working on robust masonry structures, this lintel offers reliable strength and corrosion resistance thanks to its galvanised steel construction. Please note, a separate flexible damp proof course (DPC) must be fitted during installation.

Application

Specifically designed for cavity walls with a 90-105mm cavity and an inner leaf thickness of 110-115mm, the CXL290 lintel provides structural support over wide openings in load-bearing walls. It’s suitable for use in residential, commercial, and industrial builds where heavy masonry loads are present. Ensure the lintel is laterally restrained and installed with a minimum 200mm bearing at each end to meet load-bearing requirements.

Dimension

Length: 5500mm (18ft 1in)
Suitable for cavity widths: 90-105mm
Inner leaf thickness: 110-115mm

Material

Grade S275 structural steel to BS EN 10025:2004
Post-manufacture galvanised finish to BS EN ISO 1461:1999 for enhanced corrosion protection

Type

Extreme load cavity wall lintel

Images are for illustration purposes only. For additional options such as expanded metal mesh attached to the base plate, please contact us. Standard lengths are available in 50mm increments up to 6600mm.

More Information

More Information
MPN	CXL290/5500
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	90-105mm
Length	5500mm
Weight	239.250000
Manufacturer	Catnic
Sap Id	cxl29055
