Catnic CXL290 Extreme Load Cavity Wall Lintel - 2150mm

SKU

cxl290215

£631.63 £526.36

Product Information

Catnic CXL290 Extreme Load Cavity Wall Lintel, 2150mm (7ft 1in) length
Designed for 90-105mm cavity widths with 110-115mm inner leaf thickness
Manufactured from Grade S275 structural steel with a post-galvanised finish for corrosion resistance
Supports high structural loads with lateral restraint and 200mm end bearing requirements
Separate flexible DPC must be installed during construction for moisture protection

Details

The Catnic CXL290 Extreme Load Cavity Wall Lintel at 2150mm is engineered for builders and contractors handling demanding structural builds requiring robust support over cavity walls. Its galvanised finish and heavy-duty design make it a reliable choice for projects involving 90-105mm cavities and 110-115mm inner leaf walls. Please note, a separate flexible damp proof course (DPC) must be installed during construction to ensure moisture protection.

Application

Ideal for supporting heavy loads above openings in cavity wall constructions, this lintel is suited to both residential and commercial developments where structural integrity is critical. It requires lateral restraint and a minimum 200mm end bearing to perform as specified, making it perfect for serious contractors and site managers overseeing substantial masonry work.

Dimension

Length: 2150mm (7ft 1in)
Suitable cavity width: 90-105mm
Inner leaf thickness: 110-115mm
Available in standard increments up to 6600mm in 50mm steps

Material

Grade S275 structural steel plate (6mm thickness)
Universal beam section steel
Post-manufacture galvanised finish to BS EN ISO 1461:1999

Type

Extreme load cavity wall lintel

Optional expanded metal mesh can be supplied fixed to the base plate if required. Images are for illustration purposes only.

More Information

More Information
MPN	CXL290/2150
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	90-105mm
Length	2150mm
Weight	93.525000
Manufacturer	Catnic
Sap Id	cxl290215
