Catnic CXL240 Extreme Load Cavity Wall Lintel - 4000mm

SKU

cxl2404

£938.60 £782.17

Product Information

Catnic CXL240 Extreme Load Cavity Wall Lintel, length 4000mm (13ft 1in)
Designed for 50-65mm cavity walls with 110-115mm inner leaf thickness
Manufactured from Grade S275 structural steel with post galvanised finish for durability
Supports heavy structural loads with lateral restraint and 200mm end bearing
Separate flexible DPC must be installed on site during construction

Details

The Catnic CXL240 Extreme Load Cavity Wall Lintel is engineered for demanding building projects requiring robust structural support. Ideal for builders, contractors, and site managers working with cavity walls featuring a 50-65mm gap and 110-115mm inner leaf thickness, this 4000mm lintel offers reliability where heavy loads are involved. Please note, a separate flexible DPC must be installed during construction.

Application

This lintel is specifically designed for use in cavity wall construction where extreme load-bearing capacity is essential. It provides dependable support over openings such as doors and windows on solid masonry walls, ensuring structural integrity in residential and commercial builds. Suitable for serious projects where compliance with building standards and long-term durability are critical.

Dimension

Length: 4000mm (13ft 1in)
Suitable for cavity widths: 50-65mm
Inner leaf thickness: 110-115mm
Standard lengths available in 50mm increments up to 6600mm

Material

Structural steel Grade S275 to BS EN10025:2004
6mm structural grade steel plate
Post-manufacture galvanised finish to BS EN ISO 1461:1999 for enhanced corrosion resistance

Type

Extreme load cavity wall lintel

For optimal performance, the lintel must be laterally restrained with minimum 200mm end bearing supports and inner to outer load ratios between 5:1 and 19:1. Optional expanded metal mesh can be supplied fixed to the base plate to assist with plaster keying if required.

More Information

More Information
MPN	CXL240/4000
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	50-65mm
Length	4000mm
Weight	164.400000
Manufacturer	Catnic
Sap Id	cxl2404
