Catnic CXL240 Extreme Load Cavity Wall Lintel - 3300mm

SKU

cxl24033

£774.35 £645.29

Product Information

Catnic CXL240 Extreme Load Cavity Wall Lintel, length 3300mm (10ft 10in) for substantial structural demands
Designed for 50-65mm cavity widths and 110-115mm inner leaf thicknesses, ideal for complex masonry projects
Manufactured from Grade S275 structural steel with a post-galvanised finish for enhanced corrosion resistance
Supports heavy loads when installed with 200mm end bearings and proper lateral restraint
Separate flexible DPC required; lintel supplied without DPC for site fitting

Details

The Catnic CXL240 Extreme Load Cavity Wall Lintel is engineered for structural applications demanding high load-bearing capacity. At 3300mm in length, it’s suited for builders, contractors and site managers working on cavity walls with 50-65mm cavities and 110-115mm inner leaves. This lintel combines robust construction with a post-galvanised finish, ensuring durability and reliability on site. Please note, a separate flexible damp proof course (DPC) must be installed during construction, as it is not included.

Application

This lintel is ideal for supporting heavy masonry loads in cavity wall construction, particularly where extreme loading conditions exist. It is frequently specified for commercial and residential developments where structural integrity is critical. The lintel requires lateral restraint and a minimum 200mm bearing at each end to perform effectively. It can be used in both new builds and refurbishment projects where cavity widths and inner leaf thicknesses fall within the specified range.

Dimension

Length: 3300mm (10ft 10in)
Suitable for cavity widths: 50-65mm
Inner leaf thickness: 110-115mm

Material

Grade S275 structural steel plate (6mm thickness)
Post galvanised finish to BS EN ISO 1461:1999 for corrosion resistance

Type

Extreme load cavity wall lintel

To achieve the specified load ratings, ensure the lintel is laterally restrained and properly supported with 200mm end bearings. The lintel is supplied without a damp proof course; a flexible DPC must be installed separately during construction. Optional extras such as expanded metal mesh fixed to the base plate are available upon request.

More Information

More Information
MPN	CXL240/3300
Type	External Solid Wall Lintels
Loading	Extreme Duty
Wide Inner Leaf	110-115mm
Cavity Size	50-65mm
Length	3300mm
Weight	135.630000
Manufacturer	Catnic
Sap Id	cxl24033
