Catnic Extra Heavy Duty Cavity Wall Lintel CX130/125 1350mm

SKU

cat_CX1301251350

£196.66 £163.88

Product Information

Catnic Extra Heavy Duty Cavity Wall Lintel CX130/125, length 1350mm (4ft 5in)
Designed for inner leaf thickness 125-140mm and cavity width 130-145mm
Features built-in DPC to speed up installation and prevent cold bridging
Duplex corrosion protection ensures maximum durability on site
Built-in plaster key with staggered slots for secure render adhesion

Details

The Catnic Extra Heavy Duty Cavity Wall Lintel CX130/125 at 1350mm is engineered for builders and contractors requiring reliable lintels for wide inner leaf cavity wall constructions. Its robust design supports heavy loads while integrating thermal efficiency features and corrosion protection to enhance building longevity. Please note, this lintel includes built-in DPC and plaster key features to simplify installation and finishing.

Application

This lintel is ideal for use in cavity walls with an inner leaf thickness between 125 and 140mm and cavity widths from 130 to 145mm, commonly found in residential and commercial masonry projects. It supports structural openings such as doors and windows, providing extra heavy duty strength to accommodate heavier loads or larger spans. The built-in damp proof course (DPC) minimises cold bridging, helping maintain thermal efficiency on site.

Dimension

Length: 1350mm (4ft 5in)
Inner leaf thickness: 125 - 140mm
Cavity width: 130 - 145mm
Outer leaf thickness: 100 - 105mm

Material

Galvanised steel with duplex corrosion protection
Built-in damp proof course (DPC) membrane

Type

Extra heavy duty cavity wall lintel
Wide inner leaf lintel

More Information

More Information
MPN	CX130/1251350
Type	Cavity Wall Lintels
Loading	Extra Heavy Duty
Wide Inner Leaf	125-140mm
Outer Leaf	100-105mm
Cavity Size	130-145mm
Length	1350mm
Weight	24.450000
Manufacturer	Catnic
Sap Id	cat_CX1301251350
