Catnic Standard Duty Cavity Wall CG150/100 3300mm

SKU

cg15033-S

£350.76 £292.30

Product Information

Catnic Standard Duty Cavity Wall Lintel CG150/100, length 3300mm (10ft 10in)
Designed for cavity widths of 150-165mm and inner leaf thickness 100-115mm
Features built-in damp proof course (DPC) to simplify installation and protect against moisture
Duplex corrosion protection for enhanced durability and long-term reliability on site
Built-in plaster key with staggered slots for strong plaster adhesion and finish

Details

The Catnic Standard Duty Cavity Wall Lintel CG150/100 at 3300mm is engineered for builders, contractors, and site managers seeking dependable support in cavity wall construction. Its robust design and integrated features ensure structural integrity while aiding thermal efficiency, making it a smart choice for both residential and commercial developments.

Application

This lintel is specifically suited to cavity walls with an inner leaf thickness between 100-115mm and a cavity width of 150-165mm. It supports brickwork or blockwork above openings such as windows and doors, providing essential load-bearing capacity. The built-in damp proof course (DPC) helps prevent moisture penetration, while the plaster key slots enable a clean, secure plaster finish on-site.

Dimension

Length: 3300mm (10ft 10in)
Inner leaf thickness: 100-115mm
Cavity width: 150-165mm
Outer leaf thickness: 100-105mm

Material

Galvanised steel with duplex corrosion protection for enhanced durability
Perforated steel baseplate featuring plaster key slots
Integrated damp proof course (DPC) membrane to resist moisture

Type

Standard duty cavity wall lintel

Please note: This lintel includes an integrated damp proof course and corrosion protection to ensure longevity on site.

More Information

More Information
MPN	CG150/1003300
Type	Cavity Wall Lintels
Loading	Standard Duty
Wide Inner Leaf	100-115mm
Cavity Size	150-165mm
Length	3300mm
Weight	55.110000
Manufacturer	Catnic
Sap Id	cg15033-S
